Sewage Treatment Equipment - Indian Manufacturers, Suppliers and Exporters

Sewage Treatment Equipment

Leading Manufacturer of modular- STP  with MBBR, Pre fabricated sewage treatment plant, underground sewage treatment plant, sewage treatment, below ground sewage treatment plant and conventional sewage treatment plant from Ahmedabad Gujarat India.

Sewage Treatment Equipment – Indian Manufacturers, Suppliers and Exporters


Shubham Inc has earned its place in the market as one of the most trusted, and recommended supplier and manufacturer of Sewage Treatment Plants and Water Treatment Plants.We are an end to end server provider right from Design, Supplies, Erection, Commissioning and Operations & Maintenance. Our experience includes collaborations with European, American, Israel, UAE, and Asian Companies.

Modular- STP with MBBR

The fully pre-assembled and factory tested Bio-Accelerator 3600™ modular Sewage Treatment plant is supplied in an ISO shipping container format for ease of transportation. Bioreactor, settling tanks & chlorine contact tanks are open topped with safety railings around access points. RAS Pump, aeration blower, dosing systems, Tertiary system, monitoring and control systems are skid mounted and with effective weather protection. The factory fitted and tested system along with semi / Automatic control panel includes full process Monitoring and data logging functions. Full telemetry including remote control is available as an option.

The Bio-Accelerator 3600™ is designed to require minimal operator supervision making it ideal for installation in remote locations.

TREATMENT PROCESS

Bio-Accelerator 3600™Modular sewage treatment plant is a fully/Semi Automated wastewater treatment system incorporating the following process stages:
 1. Inlet screening
2. Primary / Anoxic tank - DE nitrification (Optional)
3. Aeration Tank with UV resistance bio media.
4. Secondary Settling Tank with PP tube media.
5. Chlorine Contact tank
6. RAS and sludge removal
7. Tertiary Treatment for polishing

WORKING PRINCIPAL

The heart of the Bio-Accelerator 3600™ is design of aeration tank and bio-media as it removes organic impurities through a biological process. The biological process involves growing millions of bacteria that eat up organic impurities. Thousands of Virgin PP media pieces provide larger surface area for quick bacterial growth.  Bacteria get attached to the surface of media-piece sand gets detached after attaining mass and age, giving room to other bacteria to grow at the surface of the media. Continuous and right supply of air through Diffusers provides mobility to the media and the sewage, for accelerated biological growth of bacteria…   and provides vital oxygen for bacterial growth.  The Accelerator 360o™ technology ensures that Food and Mass Ratio is continuously maintained uninterruptedly throughout the process for desired level of Mixed Suspended Solids (MLSS) which is critical for subsequent processes. The mixed- largely free of organic impurities, with controlled levels of BOD and COD, overflows to the next chamber for settling and filtration process.

Benefits

  • Small footprints reduce land use.
  • Expandable and flexible designs
  • Completely above ground installation.
  • Easy to Transport, relocate, install & Expand.
  • High removal efficiency for nitrogen, BOD & COD,
  • Treated Water reuse in irrigation and grey water applications.
  • Minimum maintenance requirements.
  • Full technical, installation and operation support from trained and experienced Shubham Team.
  • Proven Technology with reliable performance.
  • Reuse of Wastewater in gardening application.

Typical Applications:

Packaged Sewage Treatment Plants are ideal for the following applications:
  • Housing Project.
  • Schools & hostels.
  • Industrial Office &Parks.
  • Small Communities.
  • Recreational camps & travels trailer parks.
  • Shopping Centres.
  • Restaurants.
  • Resorts, Golf Courses and country clubs.
  • Rural Area Schools
  • Hospitals.

Conventional Sewage Treatment Plant

We hold expertise in meeting the demands of Conventional Sewage Treatment Plant. These are precision designed using the skills of our product designers and construction staff. Our process expertise also allows us to deliver in these customized changes as demanded by our customers. Created by leading industry experts, these Conventional Sewage Treatment Plant are easy to install or use and have superb capacity. Specifications:
  • Water outtake: GB 17303-1998 purified water
  • Electric current:  ≤10US/cm
  • Bacteria:≤10m/m3

Sewage Treatment Systems

We offer a broad spectrum of packaged sewage treatment systems to handle domestic and industrial sewage originating from industrial residences, large commercial complexes, small and medium industries. Standard modules facilitate a shorter delivery period. The completely pre engineered units require very less civil works and can be erected and commissioned in a short time span. The pre fabricated units are independent of site location (i.e.) in places where there is space constraint or cost of space is very high, these units can be located either on the top of the building, structures or in the basement. Process Benefits
  • Compact Design- A fraction of the size of conventional systems
  • Expandable- Capacity can be easily upgraded by simply increasing the fill fraction of biofilm carriers
  • Single Pass Process- No return activated sludge stream required
  • Load Responsive- Actively sloughed biofilm automatically responds to load fluctuations
  • Minimal Maintenance- No F/M ratios or MLSS levels to maintain
MBBR processes are an excellent solution for common wastewater applications including:
  • BOD Reduction
  • Nitrification
  • Total Nitrogen Removal
Advantages of Package Sewage Treatment Plant
  • Small Footprint
  • Cost effective plant upgrades
  • Modular preconstructed systems
  • Durable UV resistant HDPE biofilm carriers.
  • Cold climate nitrification/denitrification
  • Minimal solids and sludge generation
  • Expandable and flexible designs
  • Minimal O&M requirements
  • Straight Forward Process treatment and fully / semi automatic controls.
  • Continuous flow.

Moving Bed Biofilm Reactors

There are areas within the cities, towns and villages that are impossible to cover under centralized wastewater treatment system, to offer perfect solution for the same, Shubham steps in this field. Shubham package sewage treatment plant type wastewater treatment system is compact, effective and economical for wastewater treatment in decentralized manner.

We offer a broad spectrum of packaged sewage treatment systems to handle domestic and industrial sewage originating from industrial residences, large commercial complexes, small and medium industries.Standard modules facilitate a shorter delivery period. The completely pre engineered units require very less civil works and can be erected and commissioned in a short time span. The pre fabricated units are independent of site location (i.e.) in places where there is space constraint or cost of space is very high, these units can be located either on the top of the building, structures or in the basement

Working Principle /Process/operation:

The packaged units work on a media based biological degradation. The specifically developed media made from UV stabilized and chemically resistant propylene offers an ideal condition for growth of micro organisms to degrade the incoming organic contaminants.

 The use of media also reduces the aeration tank sizes substantially thereby reducing the footprint of Sewage Treatment plant. The process air required is provided by means of twin lobe type air blower which transfers air through rugged EPDM diffusers. The media also substantially reduces the sludge generation from these units

Advantages of Package Sewage Treatment Plant
  • Small Footprint
  • Cost effective plant upgrades
  • Modular preconstructed systems
  • Durable UV resistant HDPE biofilm carriers.
  • Cold climate nitrification/denitrification
  • Minimal solids and sludge generation
  • Expandable and flexible designs
  • Minimal O&M requirements
  • Straight Forward Process treatment and fully / semi automatic controls.
  • Continuous flow.
  • Suitable for both Industrial and Institution Domestic Wastewater.
  • Standard Modular Steel Construction allows for ease of installation as well as process and flow upgrades.
  • Internals & ancillary equipment only can be supplied for installation in pre-constructed concrete basin.
  • Applicable treatment for Waster reuse in irrigation and grey water applications.
  • Minimum Operator attendance required.
  • Minimum maintenance requirements.
Applications:
  • Packaged Sewage Treatment Plants are ideal for the following applications:
  • Residential Colonies
  • Commercial Complexes
  • Software Parks
  • Hotels & Restaurants
  • Resorts & Amusement Parks
  • Small And Medium Industries
 Contact Shubham INC. Representative for further details on info@shubhamindia.com visit : - www.shubhamindia.com
