Monday, 30 July 2018

Dual Media Filter - Water treatment by Shubham Inc

Overview Dual Media Filter

Dual Media Filter is used for removal of suspended solids, turbidity and some part of colour and odour from Water & Wastewater.. We, at Shubham offer Series of filters at a low cost, reliable and highly efficient way to filter your water.
Our unique design of Dual Media filter ensures the maximum utilization of the surface area, lesser pressure drop across the filter bed and effective removal of the impurities even under the conditions of high filtration rate compare to pressure sand filter.

Dual Media filters

Shubham DMFs are available in diameters from 0.225 Mts. to 4.0 Mts.(vertically) and in length from 3.0 Mts. mm to 11 Mts. (Horizontally) with flow rates up to 400M3/Hr. These rugged, pre-engineered, pre-assembled units minimize installation and start-up costs. Whether you require ROfeed process water or filtered water, Shubham can full fill applications requirement

Manufacturer and Exporter of Water treatment plants, sewage treatment plants, effluent treatment plants offered by Shubham inc Wastewater Management Company, India

Working Principle

Raw water is passed through the dualmedia filter, contain anthracite along with fine sand reinforced by marbled and gravels. These filters consist of a coating of anthracite (1.25-2.5mm) resting on a coating of fine sand (0.6-1.5mm) Anthracite is coarse and has more dirt holding capacity as compared to fine sand.
During the filtration cycle the largest particles are strained out by the anthracite then the sand traps the rest of the particulate matter through a combination of adhesion and straining. Since the particles in the water are filtered out at various depths in a dual media filter,  the filter does not clog as quickly as all of the particles were  caught by the top layer.

Technical Specification

Flow:1M3/Hr. – 400 M3/Hr.
Inlet TSS:Up to 50 Mg/L
Inlet Turbidity:Up to 40 NTU
Filtration Velocity:12 to 18 M3/Hr./M2
Diameter (Vertical Vessel):0.225 Mts. – 4.0 Mts.
Length (Horizontal Vessel):3.00 Mts. – 11.0 Mts.
MOC:FRP / Mid Steel / Stainless Steel Coating / lining : Epoxy / FRP / Rubber Lined
Filtration Rating:Up to 10 Micron
Design Code:ASME / IS
Design Pressure:Up to 10 Bar
Working Pressure:1.1 to 3.5 Bar
Clear Pressure Drop:0.3 bar
Top distribution system:bell mouth
Bottom distribution system:Strainer plate or Header & laterals.

Salient Features

  • Simple design maximizes reliability and efficiency
  • Two layers of filtration media
  • Filtration rating up to 10 – 30 Microns
  • Standard and effective quartz sand media.
  • Low Pressure drop across the vessel
  • FRP, MSRL, MSEP & SS Vessels are available.
  • Manual, Semi-Automatic and Automatic features are provided
  • Pre-assembled construction minimizes start-up time and installation costs
  • Structural steel legs provide rigid support of vessel for safety
  • Air scouring available for high flow pressure vessel.
  • Proven design of internal distribution and collection system.

Benefits

  • Efficient Turbidity and TSS Removal
  • High filtration rate
  • Filtration efficiency is up to 5.0 ppm suspended particles
  • Easy operation & maintenance
  • Wide range in material of construction
  • Economical way of production & design
  • Low Energy requirement
  • Can accommodate seasonal fluctuations in flow rate
  • Long filter cycles between backwashing with minimum loss of pressure.

Application

Drinking Water Treatment
  • Turbidity & Total Suspended Solid Removal
  • Iron Removal
  • Manganese removal
  • Fluoride Removal
  • Arsenic Removal
  • Pre- treatment to reverse Osmosis Plant
  • Pre- treatment to Desalination Plant
River Water Treatment
  • Turbidity & Total Suspended Solid Removal
Ground Water Treatment
  • Turbidity & Total Suspended Solid Removal
  • Iron Removal
  • Manganese removal
  • Fluoride Removal
  • Arsenic Removal
Waste Water Treatment Plant
  • Turbidity & Total Suspended Solid Removal
  • Septic Tank expansion
Swimming Pool Filtration
  • Turbidity & Total Suspended Solid Removal
Cooling Tower & Process Water Treatment
  • Turbidity & Total Suspended Solid Removal
  • Side Stream Filter
  • Full Stream Filter
  • Make up water Filter

Friday, 25 May 2018

No electricity Septic Systems for domestic applications

You need a sewage treatment plant?

Go for a Shubham Inc! The Original, low-maintenance, non-electrical waste water treatment plant; Our plant uses no electricity for the treatment process.

BIOROCK sewage treatment plants are easy to install and clean the sewage to an astonishing level of purity for the same price than the leading electric sewage treatment plants.

No electricity, low maintenance, high performance: BIOROCK, the best Sewage Treatment System for domestic applications.
Non-Electric Sewage Treatment Plants for domestic waste water

BIOROCK

Non-Electric Sewage Treatment Plants for domestic waste water BIOROCK was established in 1988 and is now an internationally acclaimed and experienced company and industry leading in compact wastewater treatment technology. BIOROCK systems have already been installed worldwide in the past 25 years. Our proven performance leads to trust of both the users of our technology and our supplier’s network, which is the basis of our success.

Non-Electric treatment process

  • Initially the raw sewage (A) enters a primary tank (PT, B) to provide separation and the breakdown of organic solids (Primary Treatment). The sewage then passes through an effluent filter before discharging into the BIOROCK® unit which incorporates the well proven aerobic digestion process (Secondary Treatment) and filtration process (Tertiary Treatment).
  • BIOROCK uses a material with huge surface area which allows colonization of the necessary bacteria, a process which is essential for the effective treatment of domestic wastewater.
  • The BIOROCK media is highly resistant to degradation and remains extremely stable over the long term – our 25 years’ experience in the industry being proof of this.
BIOROCK offers 2 discharge options :
1. BIOROCK gravity discharge
2. BIOROCK high-level discharge

Our high level discharge system is equipped with a reliable, high-quality pump kit. This kit is delivered “pre-assembled” for ease and speed of installation.
Non electrical STP
Installation for all type of ground conditions and applications.
  • High ground-water sites.
  • Reinforced and durable, the BIOROCK units and Primary tanks are reinforced as standard enabling them to be structurally sound in all ground conditions.
  • The BIOROCK System has the ability to handle inter mittent (seasonal) wastewater loadings, even during long absence periods
  • Holiday Homes, Campsites, Caravan Parks, etc.
  • The system can also handle low utilization levels without compromising the treated effluent quality.
Contact Shubham INC. Representative for further details on info@shubhamindia.com visit : – www.shubhamindia.com

Monday, 2 April 2018

Newly Launched Zero Energy - Sewage Treatment Plant

Zero Energy - Sewage Treatment Plant

Shubham Inc is now exclusive partner of Biorock. Now worlds best Non Electric Sewage Treatment Plant is available in India.

Zero Energy - Sewage Treatment Plant

Looking for "Sales Partner / Distributor" in India for our Newly Launched Zero Energy - Sewage Treatment Plant.

The best residential sewage water treatment system without electricity, zero energy.





Salient Features:
• Underground structure with compact design & completely covered plant.
• No foul odour around the STP area or in the receiving environment.
• Does not require continuous monitoring and operation.
• Works well with inconsistent grey water flow.
• Minimal sludge generation.
• Zero liquid from STP.
• Extremely low Maintenance.
• without electricity, zero energy.
• Minimal foot Print
• Semi automatic and automatic plant operation.
• Treated water quality within permissible limit
• Environmentally Safe to treated sewage water dispose in Land or Water.
• Treated water can be reuse for gardening, toilet flushing, landscape, irrigation, cooling towers etc.

Multiple advantages

Revolutionary technology

  • No electricityrequired
  • No moving parts
  • 24 hour start-up
  • Long absence periods acceptable

Unique comfort

  • Completely silent
  • Lowest operational costs
  • Superb effluent quality
  • Septic tank conversion unit (retrofit)

Sustainability highlights

  • Long lifespan BIOROCK Media
  • Low carbon footprint
  • Minimum annual maintenance
  • Long de-sludge interval

Shubham Inc, A Water and Waste Water Management Company

A-305, ShivalikYash 132 Ft. Ring Road, Shastri Nagar BRTS,Naranpura Ahmedabad, Gujarat, India 380009
Phone: +917940086151 Phone: +917940086154
Email : info@shubhamindia.com  Web : www.shubhamindia.com Surat | Baroda | Rajkot | Delhi | Mumbai | Pune | Indore | Udaipur | Ahmedabad

Tuesday, 6 March 2018

Domestic and Residential STPs for Individual House, Weekend homes, farmhouse, Villas.

Domestic & Residential Sewage treatment plants for Individual House, Weekend homes, farmhouse, Villas.

Shubham Inc is now exclusive partner of Biorock. Now worlds best Non Electrical Sewage Treatment Plant is available in India.

Domestic & Residential Sewage treatment plants for Individual House, Weekend homes, farmhouse, Villas.

Weekend Home Non Electrical Sewage Treatment Plant

The best residential sewage water treatment system without electricity, zero energy.

Weekend homes, farmhouse and villas have uneven supply of sewage is very less compared to residential building. Supply of domestic water is also limited. Shubham Inc provide a customized solution is used to collect, treat sewage water from an individual dwelling, villas, weekend homes and treated the sewage water up to reclaimed/reuse water quality and mainly reduce the manpower operation cost and daily maintenance cost.

Salient Features:
• Underground structure with compact design & completely covered plant.
• No foul odour around the STP area or in the receiving environment.
• Does not require continuous monitoring and operation.
• Works well with inconsistent grey water flow.
• Minimal sludge generation.
• Zero liquid from STP.
• Extremely low Maintenance.
• without electricity, zero energy.
• Minimal foot Print
• Semi automatic and automatic plant operation.
• Treated water quality within permissible limit
• Environmentally Safe to treated sewage water dispose in Land or Water.
• Treated water can be reuse for gardening, toilet flushing, landscape, irrigation, cooling towers etc.

Multiple advantages

Revolutionary technology

  • No electricityrequired
  • No moving parts
  • 24 hour start-up
  • Long absence periods acceptable

Unique comfort

  • Completely silent
  • Lowest operational costs
  • Superb effluent quality
  • Septic tank conversion unit (retrofit)

Sustainability highlights

  • Long lifespan BIOROCK Media
  • Low carbon footprint
  • Minimum annual maintenance
  • Long de-sludge interval

Reach Us

Vinod Malviya (Director)

Shubham Inc, A Water and Waste Water Management Company

A-305, ShivalikYash 132 Ft. Ring Road, Shastri Nagar BRTS,Naranpura Ahmedabad, Gujarat, India 380009
Phone: +917940086151 Phone: +917940086154
Email : info@shubhamindia.com  Web : www.shubhamindia.com Surat | Baroda | Rajkot | Delhi | Mumbai | Pune | Indore | Udaipur | Ahmedabad

Wednesday, 27 December 2017

Wastewater Treatment Plant With Attached Bio-growth by Shubham Inc

Wastewater Treatment Plants

Providing you the best range of wastewater treatment plant with attached bio-growth, wastewater treatment plants, under ground wastewater treatment plant, moving bed bioreactor, frp sewage treatment plant and moving bed bio reactor mbbr with effective & timely delivery.

Renowned among the best in the industry, we indulge us in manufacturing and supplies of an amazing range of   Wastewater Treatment Plant With Attached Bio-growth under our Wastewater Treatment Plant gamut. These Machines as manufactured using latest technology are imparted with assured durability.The factory fitted and tested system along with semi / Automatic control panel includes full process Monitoring and data logging functions. Full telemetry including remote control is available as an option. The Bio-Accelerator 3600 is designed to require minimal operator supervision making it ideal for installation in remote locations.Priced very competitively, the quality of these machines proves a delight to our clients.



TREATMENT PROCESS

Bio-Accelerator 3600™ Modular sewage treatment plant is a fully/Semi Automated wastewater treatment system incorporating the following process stages: 1. Inlet screening 2. Primary / Anoxic tank - DE nitrification (Optional) 3. Aeration Tank with UV resistance bio media. 4. Secondary Settling Tank with PP tube media. 5. Chlorine Contact tank 6. RAS and sludge removal 7. Tertiary Treatment for polishing

WORKING PRINCIPAL

The heart of the Bio-Accelerator 3600™ is design of aeration tank and bio-media as it removes organic impurities through a biological process. The biological process involves growing millions of bacteria that eat up organic impurities. Thousands of Virgin PP media pieces provide larger surface area for quick bacterial growth. Bacteria get attached to the surface of media-piece sand gets detached after attaining mass and age, giving room to other bacteria to grow at the surface of the media.

Continuous and right supply of air through Diffusers provides mobility to the media and the sewage, for accelerated biological growth of bacteria… and provides vital oxygen for bacterial growth. The Accelerator 360o™ technology ensures that Food and Mass Ratio is continuously maintained uninterruptedly throughout the process for desired level of Mixed Liquor Suspended Solids (MLSS) which is critical for subsequent processes. The mixed-liquor largely free of organic impurities, with controlled levels of BOD and COD, overflows to the next chamber for settling and filtration process.



    Benefits
  • Small footprints reduce land use.
  • Expandable and flexible designs
  • Completely above ground installation.
  • Easy to Transport, relocate, install & Expand.
  • High removal efficiency for nitrogen, BOD & COD,
  • Treated Water reuse in irrigation and grey water applications.
  • Minimum maintenance requirements.
  • Full technical, installation and operation support from trained and experienced Shubham Team.
  • Proven Technology with reliable performance.
  • Reuse of Wastewater in gardening application.
Typical Applications:
  • Packaged Sewage Treatment Plants are ideal for the following applications:
  • Housing Project.
  • Schools & hostels.
  • Industrial Office &Parks.
  • Recreational camps & travels trailer parks.
  • Shopping Centres.
  • Restaurants.
  • Resorts, Golf Courses and country clubs.
  • Hospitals
Product Details:
Automatic Grade Automatic, Semi-Automatic, Manual
Plant Type Sewage Treatment Plant, Wastewater Treatment Plant, Effluent Treatment Plant, Drinking Water Treatment Plant
Treatment Technique Clarifier, Fluidized Aerated Reactor, Mixed Bed Bio Reactor, Bio Tower


Reach Us

Vinod Malviya (Director)

Shubham Inc, A Water and Waste Water Management Company
A-305, ShivalikYash 132 Ft. Ring Road, Shastri Nagar BRTS,Naranpura Ahmedabad, Gujarat, India 380009
Phone: +917940086151 Phone: +917940086154
Email : info@shubhamindia.com  Web : www.shubhamindia.com Surat | Baroda | Rajkot | Delhi | Mumbai | Pune | Indore | Udaipur | Ahmedabad

Thursday, 23 November 2017

Prefabricated Sewage Treatment Plant by Shubham India

Prefabricated Sewage Treatment Plant

The fully pre-assembled and factory tested Bio-Accelerator 3600™ modular Sewage Treatment plant is supplied in an ISO shipping container format for ease of transportation.

Bioreactor, settling tanks & chlorine contact tanks are open topped with safety railings around access points. RAS Pump, aeration blower, dosing systems, Tertiary system, monitoring, and control systems are skid mounted and with effective weather protection.

We at Shubham, Supplier Prefabricated Sewage Treatment Plant, we offer a variety of sewage treatment plant from conventional to innovative technology and modular to onsite treatment plant as per customer’s relevance and area availability as in Ahmedabad, Surat, Rajkot, Baroda, Gujarat and across the India.

The factory fitted and tested system along with semi / Automatic control panel includes full process Monitoring and data logging functions. Full telemetry including remote control is available as an option. The Bio-Accelerator 3600™ is designed to require minimal operator supervision making it ideal for installation in remote locations.

TREATMENT PROCESS

Bio-Accelerator 3600™ Modular sewage treatment plant is a fully/Semi-Automated wastewater treatment system incorporating the following process stages:

1. Inlet screening
2. Primary / Anoxic tank - DE nitrification (Optional)
3. Aeration Tank with UV resistance bio media.
4. Secondary Settling Tank with PP tube media.
5. Chlorine Contact tank
6. RAS and sludge removal
7. Tertiary Treatment for polishing

Prefabricated Sewage Treatment Plant by Shubham India

WORKING PRINCIPLE

The heart of the Bio-Accelerator 3600™ is the design of aeration tank and bio-media as it removes organic impurities through a biological process. The biological process involves growing millions of bacteria that eat up organic impurities.

Thousands of Virgin PP media pieces provide larger surface area for quick bacterial growth.  Bacteria get attached to the surface of media-piece sand gets detached after attaining mass and age, giving room to other bacteria to grow at the surface of the media.

Continuous and right supply of air through Diffusers provides mobility to the media and the sewage, for the accelerated biological growth of bacteria…   and provides vital oxygen for bacterial growth.  The Accelerator 360o™ technology ensures that Food and Mass Ratio is continuously maintained uninterruptedly throughout the process for the desired level of Mixed Suspended Solids (MLSS) which is critical for subsequent processes.

The mixed- largely free of organic impurities, with controlled levels of BOD and COD, overflows to the next chamber for settling and filtration process.


Benefits
  • Small footprints reduce land use.
  • Expandable and flexible designs
  • Completely above ground installation.
  • Easy to Transport, relocate, install & Expand.
  • High removal efficiency for nitrogen, BOD & COD,
  • Treated Water reuse in irrigation and greywater applications.
  • Minimum maintenance requirements.
  • Full technical, installation and operation support from trained and experienced Shubham Team.
  • Proven Technology with reliable performance.
  • Reuse of Wastewater in a gardening application.
Typical Applications:  Prefabricated Sewage Treatment Plants are ideal for the following applications:
  • Housing Project.
  • Schools & hostels.
  • Industrial Office &Parks.
  • Recreational camps & travels trailer parks.
  • Shopping Centres.
  • Restaurants.
  • Resorts, Golf Courses and country clubs.
  • Rural Area Schools
  • Hospitals.
From automobiles to food and retail business; from daily cleaning and washing to plain drinking, WATER is the No.# 1 resource that we need for sustenance. For years, we assumed that this resource is not just free, it will also last forever. We made irresponsible use of it and we now face the prospect of depletion due to massive-scale mismanagement and pollution caused by water.

By considering environmental responsibility towards the water, Shubham Inc.has expanded its foray into Water and Sewage Water Treatment Plants. Shubham‘s product range mainly split into two markets vertical Water Treatment & Wastewater Treatment.

We Shubham India are manufacturer and supplier of Sewage Treatment Plant and Water Treatment Plant products such as Industrial RO Plant, Ultra filtration Plant, Pressure Sand Filter, Multi Grade Sand Filter, Dual media Filter, Side stream filters, Water Softener Plant, Demineralization, Mix bed Unit, RO Plant and many more whereas Waste water treatment product range consists of conventional Sewage Treatment plant, Advance Bio- Accelerator 360[ MBBR ], Bio Hybrid [MBR], Package Sewage Treatment Plant, Underground FRP Sewage Treatment Plant, Septic Tanks, Grey Water Treatment, Laundry Water Treatment, ultra-Latest Electra-rapid (electro Coagulation), plant as an end-to-end service provider.

We use the best-in-class technology and cutting-edge tools to foster high-quality, sustainable, community-level water supply projects in Gujarat, India across the Ahmedabad, Surat, Rajkot and Baroda.

We Shubham India also offer innovative solutions to communities that are serious about self-managing their water supply problems. Shubham delivers safe, cost-effective and sustainable water, wastewater and energy utility infrastructure solutions to businesses and communities across the countries who are interested in minimizing their carbon footprint.

Reach Us

Vinod Malviya (Director)

Shubham Inc, A Water and Wastewater Management Company
A-305, Shivalik Yash 132 Ft. Ring Road, Shastri Nagar BRTS, Naranpura Ahmedabad, Gujarat, India 380009
Phone: +917940086151 Phone: +917940086154
Email: info@shubhamindia.com  Web: www.shubhamindia.com Surat | Baroda | Rajkot | Delhi | Mumbai | Pune | Indore | Udaipur | Ahmedabad

Tuesday, 31 October 2017

Water Softening Plant by Shubham India

Water Softening Plant & System:

Water is considered 'hard' when it has excessive levels of calcium and magnesium dissolved in it. Water softening plant is used for removal of total hardness dissolved in Water. We, at Shubham offer Series of water softener sat a low cost, reliable and highly efficient way to soften your water.

  Water Softening Plant & System:
 Our unique design of Water softening plant ensures the maximum utilization of the effective surface area,uniform space and linear velocity across the resin bed which provides effective contact time between water and resin bed yield soft water and prevent any precipitation and scale formation on the surface of heat exchanges and any process equipment where water is being used for further application.

Shubham water softeners are available in diameters from 0.225 Mts. to 4.0 Mts. with the flow ratesup to 250M3/Hr. and OBR up to 2200 M3@400 PPM hardness. These Strong, pre-engineered, pre-assembled units minimize installation land startup costs. Our Water Softener Plant is acclaimed in the market for cost efficiency and consistent functioning.

Operating Principle of our Water Softening Plant:

Water softening is a process where Calcium and Magnesium ions are exchanged for Sodium ions. Calcium and Magnesium ions associated with Alkalinity contribute for scale formation. These ions are also called as Total hardness. The strong acid Cation exchange resin in Sodium form is used for softening the water. When the resin is exhausted, it is regenerated with brine solution (Sodium Chloride) 10 % or 15% brine solution is normally used for the regeneration. If the brine solution is passed from the bottom of the resin and service flow is from the top, then it is called as Up flow softener.
  Water Softening Plant & System:

If the service and regeneration flows are from top to bottom, then it is called as down flow softeners. The softeners are run up to the Hardness slip of 5 ppm as CaCO3 in the treated water, which is called as Industrial Zero hardness.

Salient Features:

  • Corrosion resistant resin and brine tank construction.
  • Timer-based automatic regeneration (Optional)
  • High quality softener resin provides stability and uniform size for top performance and long life.
  • Simple inline configuration for ease of installation and maintenance.
  • Range of softener systems to suit Institutional, commercial and industrial applications.
  • Available in simplex and duplex configurations for intermittent or continuous use.
  • Softeners are available in MS, MSRL, FRP, operating in Manual / Auto mode

Benefits of our Water Softening System:

  • Easy to install and operate.
  • Produces clear, soft and non – scale forming water.
  • Low operating costs.
  • Incorporates high-capacity polystyrene bead type cation exchange resin which is remarkably stable and has a long life.
  • Total Hardness removal

Applications:

  • Low Pressure Boiler feed.
  • Industry
  • Process Water
  • cooling water make-up.
  • RO Feed / Pre-treatment

Institution & Commercial & Residential

  • Water for laundry, dishwashers, boilers.
  • Car washing & General housekeeping.
  • HVAC & Cooling Tower
  • Scale prevention
  • Prevents scale formation
Reach Us

Vinod Malviya (Director)

Shubham Inc, A Water and Waste Water Management Company
A-305, ShivalikYash 132 Ft. Ring Road, Shastri Nagar BRTS,Naranpura Ahmedabad, Gujarat, India 380009
Phone: +917940086151 Phone: +917940086154
Email : info@shubhamindia.com  Web : www.shubhamindia.com

 Surat | Baroda | Rajkot | Delhi | Mumbai | Pune | Indore | Udaipur | Ahmedabad
